Descrizione
Display
| Type | TFT LCD |
| Colors | 65 K |
| Brightness | 400 cd/m² |
| Backlight | LED |
| LCD Life | 20000 hours |
| Touch Panel | 4-line industrial resistive touch screen |
| CPU | RISC ARM9 32bit 300MHz |
| Application Memoy | About 40MB |
| Real Time Clock (RTC) | Built in (Unchargeable Battery type,5 years battery life) |
| Ethernet | 1-line 10M/100M suitable |
| USB Port | 1 USB Slave 2.0 port, 1 USB Host 2.0 port |
| Download Project | USB Slave/U-disc /Ethernet |
Energia
| Supply Voltage | 24Vdc, ±10% |
| Consumption | 10 W |
Dimension
| Dimension WxHxD (mm) | 129.0 x 103.0 x 33 mm |
| Cutout Dimension WxH (mm) | 118.5 x 92.5 mm |
| Net Weight (kg) | 230 g |
